🛡️ ArmorShield™ 10-Year Roof Waterproofing System
Roof Waterproofing Services - Premium Polyurethane & Reinforced Fabric Membrane Technology - By KCS Waterproofing
The ArmorShield™ 10-Year Roof Waterproofing System is KCS Waterproofing's premium long-term roof protection solution designed for RCC concrete roofs, terraces, podium decks, and exposed concrete surfaces.
Developed specifically for Karachi's harsh weather conditions, ArmorShield™ combines advanced crack treatment, reinforced waterproofing fabric technology, and high-performance polyurethane rubber coating to create a seamless, flexible, and highly durable waterproof membrane.
Unlike conventional waterproofing methods that depend solely on coatings, ArmorShield™ utilizes a reinforced membrane system that acts as a protective shield over the entire roof surface, providing superior resistance against leakage, seepage, dampness, UV exposure, thermal expansion, and future hairline crack development.
The system is engineered to deliver long-term waterproofing performance and is backed by a 10-Year Written Warranty subject to warranty terms and conditions.
Why Roofs Fail
Most roof leakages occur due to:
Hairline and structural cracks
Thermal expansion and contraction
Aging waterproofing systems
Ponding water
UV degradation
Poor workmanship
Failed construction joints
Concrete porosity
Improper drainage slopes
Traditional waterproofing coatings often crack, lose adhesion, or deteriorate over time, allowing moisture to penetrate the concrete structure.
ArmorShield™ addresses these issues through a reinforced multi-layer waterproofing system designed for long-term performance.
ArmorShield™ Technology
The system combines:
Sealant XT100™
Advanced waterproofing compound used for:
Crack treatment
Surface stabilization
Waterproofing membrane formation
Fabric reinforcement encapsulation
Reinforced Fabric Membrane
Premium 6-ounce waterproofing fabric embedded within the waterproofing system to provide:
Tensile strength
Crack-bridging performance
Dimensional stability
Enhanced durability
Aquashield AS100™
High-performance aliphatic polyurethane rubber coating providing:
UV resistance
Weather protection
Waterproofing performance
Long-term flexibility
Crack bridging capability
7-Layer Waterproofing & Protection System
1️⃣ Surface Preparation
- Thorough cleaning of the roof surface.
- Removal of dust, loose particles, algae, laitance, old failed coatings, bitumen residues, and contaminants.
- Grinding and preparation of weak areas to ensure maximum adhesion.
- Opening and cleaning of visible cracks and damaged sections.
2️⃣ Crack, Joint & Damage Treatment
- Repair of cracks, honeycombs, leakage points, damaged concrete, and construction joints.
- Treatment of pipe penetrations, parapet wall joints, and vulnerable areas.
- Application of specialized waterproof repair materials to restore surface integrity.
3️⃣ Penetrating Primer Coat
- Application of Sealant XT100 Penetrating Primer Coat.
- Deep penetration into concrete pores.
- Binding of loose concrete dust and strengthening of the substrate.
- Improves adhesion of subsequent waterproofing layers.
4️⃣ Reinforcement Base Coat
- Application of a full-surface Sealant XT100 Base Coat.
- Encapsulation and reinforcement of repaired cracks and treated areas.
- Creation of a strong bonding layer for fabric reinforcement.
5️⃣ Cloth Reinforcement Membrane System
- Application of an additional Sealant XT100 Wet Coat.
- Embedding of premium 6-Ounce Waterproofing Canvas Cloth into the wet layer.
- Elimination of air pockets and wrinkles to ensure complete contact.
- Application of another saturation coat to fully impregnate and lock the fabric matrix.
- Formation of a reinforced waterproofing membrane capable of resisting movement and hairline crack development.
6️⃣ Protective Waterproofing Coat
- Application of a heavy-build Sealant XT100 Protective Coat over the reinforced membrane.
- Complete encapsulation of the cloth system.
- Creation of a seamless, crack-bridging waterproof barrier.
7️⃣ Dual Polyurethane Rubber Protection Coating
- Application of two coats of Aquashield AS100 Aliphatic Polyurethane Rubber Coating.
- Provides exceptional flexibility and elongation properties.
- Bridges future hairline cracks caused by thermal movement.
- Delivers superior UV resistance, weather protection, and waterproofing performance.
- Protects the entire waterproofing system from Karachi's intense sunlight, rain, humidity, and environmental exposure.
Key Performance Benefits
100% Seamless Waterproof Membrane
No joints, seams, or vulnerable overlap points.
Advanced Crack Bridging
Accommodates thermal movement and future hairline cracking.
UV Resistant Protection
Designed for Karachi's intense sunlight and heat.
Ponding Water Resistance
Performs significantly better than conventional acrylic coatings.
Structural Protection
Helps reduce moisture penetration that may contribute to concrete deterioration and reinforcement corrosion.
Long-Term Durability
Engineered as a once-in-a-decade waterproofing solution.
Recommended Applications
The ArmorShield™ System is suitable for:
Residential Homes
Villas
Bungalows
Apartment Buildings
Commercial Buildings
Shopping Centers
Warehouses
Factories
Schools
Universities
Hospitals
Government Buildings
Industrial Facilities
Areas We Serve
KCS Waterproofing provides ArmorShield™ services throughout Karachi including:
DHA Phase 1–8 and all Khayabans
Clifton
PECHS
Gulshan-e-Iqbal
Gulistan-e-Johar
North Nazimabad
Federal B Area
Bahadurabad
Tariq Road
Shahrah-e-Faisal
Korangi
Landhi
Malir
Scheme 33
Bahria Town Karachi
SITE Area
Port Qasim Industrial Areas
And surrounding regions across Sindh.
10-Year Written Warranty
Warranty Coverage
The ArmorShield™ 10-Year Written Warranty covers water leakage resulting directly from failure of the installed waterproofing system under normal service conditions.
